Filter drip coffee pod packaging machine Delivery to Saudi Arabia
C19H Automatic Ultrasonic Drip Coffee Bag Packing Machine
Type: Drip Coffee Packing Machine Series
Product model: C19H
Product name: Ultrasonic Drip Coffee Inner and Outer Bag Packing MachineOuter bag sealing controlled by the servo motor,
Purpose: bag length positioning is accurate and stable.
Feature: Outer bag sealing controlled by the servo motor , bag length positioning isaccurate and stable.
Adopts PID temperature controller for more accurate temperature adjustment.Adopts PLC control system, human-machine interface, it is very easy to operate.
All parts in direct contact with products are made of sUS304 stainless steel,ensuring reliable products output conforming to food sanitary standards.Some parts of the cylinder are imported, ensuring the accuracy and stabilityof performance.
Optional devices: flat cut device, date printer, easy tear device, etc.
Packing Material: Paper/Plastic,Plastic/Aluminum/Plastic,PaperlAluminum/Plastic,Drip coffee filter paper
Bag type: 3 side sealing
Outer Bag size: L:85~120mm,W:75~100mm (Film width200mm, Bag size: 120*100mm)
lnner Bag size: L:50~75mm, W:50~90mm (Filter paperwidth 180mm, Bag size: 90*74 mm)
Packing speed: 40~50 bags/min
Filling range: 5~15g,accuracy+0.1g/bag
Power: Single phase, 220V,50HZ,3.7KW
Air supply: ≥0.6Mpa(optional with air compressor)
Weight: 700KG
Dimension: L1400mm*W900mm*H2400mm
